Luxxor® Video Systems (LTC Camera)

Luxxor® LTC Camera

ใหม่ล่าสุด กล้อง LTC ที่สามารถใช้เชื่อมต่อกับกล้องบอร์สโคปทั้งแบบท่อตรง (Rigid Borescope) และแบบท่อโค้ง (Flexible Borescope) เพื่อต่อภาพเข้ากับหน้าจอแสดงผลหรือคอมพิวเตอร์ได้ ด้วยคุณภาพของภาพที่คมชัดระดับ HD การเชื่อมต่อด้วยพอร์ต USB3 และพอร์ต HDMI เรามั่นใจว่าสามารถเข้าถึงความต้องการในการตรวจสอบภาพแน่นอน

The New Luxxor LTC Camera attaches to any Hawkeye^® Rigid or Flexible Borescope, transforming it into a portable or benchtop video scope. The New LTC video Camera provides HD image quality at an economical price. The camera offers both USB3 and HDMI outputs. We offer several video system options to meet your application needs.

Luxxor® LTC Camera

The New Luxxor LTC Camera attaches to any Hawkeye^® Rigid or Flexible Borescope, transforming it into a complete Video Borescope System. The New LTC HD video Camera with 3MP CMOS sensor and provides crystal clear images and includes Video ToolBox Software. The camera offers both USB3 and HDMI outputs, and the Video Tool Box Software allows easy still image and video capture. It also includes a zoom feature, various cross hairs and grids, and image annotation.

Optional components like the Hawkeye^® Video Slide limit the variables with repetitive inspections while making them easier, faster, more efficient and much more comfortable for the user.

Luxxor® Video System Specifications

LTC-Camera:
Image Sensor	1/3.2” 3MP Color CMOS
Effective Pixels	2304 x 1536 pixels
Frame Rate	HDMI: 1080i 60fps USB: 720p 30fps
Video Out	USB 3.0 and HDMI
Lens Mount	C-Mount
AGC	Auto with adjustment
Operating Temp	4 to 49 deg C (40 to 120 F)
Storage Temp	-30 to +60 deg C (-22 to +140F)
Dimensions	Call for information
Software	Integrated Video Toolbox Pro* (Image and Video Capture, crosshair/grid overlay, digital zoom, image labeling)

Luxxor® Video Systems (LTC Camera)

Product	Model#
Video Kits (Borescope sold separately)
Luxxor® LTC Camera, VC-25, HDMI/USB Cables, and Power Supply	LTC-VC
Luxxor® LTC Camera, VC-25, HDMI/USB Cables, Power Supply, and Carrying Case	LTC-KIT
Luxxor® LTC Camera, VC-25, HDMI/USB Cables, Power Supply, SuperNOVA-LED and Carrying Case	LTC-NVK
Luxxor® LTC Camera, VC-25, HDMI/USB Cables, Power Supply, LXX35-LED, LXXLG, and Carrying Case	LTC-VBSM
Viewing Options
Benchtop 22″ LCD Video Monitor	HVM-22-LXC-2
Hawkeye Video Slides
Horizontal – 24″	HVSLIDE-24H-2
Horizontal – 48″	HVSLIDE-48H-2
Extra V-Block for Video Slide	HV-VBSTAGE-XY-2
Components Sold Separately
Luxxor® LTC Camera, HDMI/USB Cables, and Power Supply	LTC
HDMI Cable for Luxxor® LTC Camera	LTC-HDMICABLE
USB Cable for Luxxor® LTC Camera	LTC-USBCABLE
